Product quality control is an important part of the extruded profile production cycle. The geometry of the profile cross-section is one of the critical parameters to be thoroughly checked. And yet manual inspection does not meet modern requirements of accuracy, speed and repeatability of measurement results.

Scanfex extrusion profile geometry control system speeds up the measurement procedure and eliminates the influence of human factor.

Scanfex enables automated control of all geometry parameters of a profile sample cross-section by comparing them with drawing-based template. Comprehensive visualization of exceeded tolerances of controlled dimensions is available. The whole inspection procedure is performed with a single mouse click.
